Metal Palisade Fence D and W Shape Palisade Security Fence System

Metal Palisade Fence D and W Shape Palisade Security Fence System

बड़ी छवि :  Metal Palisade Fence D and W Shape Palisade Security Fence System

उत्पाद विवरण:
उत्पत्ति के प्लेस: हेबेई, चीन
ब्रांड नाम: XMESH
प्रमाणन: SGS
मॉडल संख्या: पलिसडे बाड़
भुगतान & नौवहन नियमों:
न्यूनतम आदेश मात्रा: 200 पीसी
पैकेजिंग विवरण: पैलेट
प्रसव के समय: 15-25 दिन
भुगतान शर्तें: टीटी, एलसी,
आपूर्ति की क्षमता: 1000 टुकड़े
विस्तृत उत्पाद विवरण
आकार: 2400 एच x 2300 एल सतह का उपचार: जस्ती
आईपीई पोस्ट आकार: 100x55 मिमी पीला: डब्ल्यू अनुभाग
प्रकार: फेंसिंग, ट्रेलिस एंड गेट्स, प्रोटेक्टिव ग्रिल प्रोफाइल या क्लैंपिंग प्रोफाइल विशेषता: आसानी से इकट्ठे, पर्यावरण के अनुकूल, निविड़ अंधकार, सड़ांध सबूत, कृंतक सबूत
धातु का प्रकार: लोहा, स्टील, लोहा या जस्ती फ़्रेम फ़िनिशिंग: पीवीसी लेपित,पाउडर लेपित,एनोडाइज्ड
फ़्रेम सामग्री: धातु दबाव उपचारित लकड़ी का प्रकार: गर्मी का इलाज, प्रकृति
रंग: सफेद, काला, हरा, नीला, लाल सतह का उपचार: जस्ती+पीवीसी लेपित, इलेक्ट्रिक \ गर्म-डूबा हुआ जस्ती+पीवीसी \ पाउडर लेपित
आवेदन: बाड़ जाल, इस्तेमाल किया, उद्यान, आवासीय प्रयोग: संरक्षण, उद्यान सजावट, भवन, उद्यान बाड़ / राजमार्ग / हवाई अड्डे
ईमेल: devin@industrialmetalmesh.com WHATSAPP: +8615369013183
प्रमुखता देना:

D shape palisade security fence

,

W shape metal fence panels

,

palisade wire mesh fence system

Metal Palisade Fence D and W Shape Palisade Security Fence System



High Security Palisade Fencing is a high spec security fencing it is designed to provide a formidable barrier against intrusion and theft. It is manufactured using hot-formed and cold-rolled substantial steel sections. It is a cost effective way to providing a high level of security to the boundary line of any property.

Metal Palisade Fence D and W Shape Palisade Security Fence System 0

Specifications of security palisade fence:


  • Material: Steel Q195, Q235, Q355.
  • Composition: pale, rail, post, and fittings
  • Pale:W pale, D pale, angle steel pale.
  • Rails:Angle steel rails, U shape rails.
  • Post: H post, Square Post

1.Instruction Of Pales Section:
------Corrugated "W"section1.5- 3.0 mm thickness, corrugated "D"section 1.5-3.9 mm thickness.
------Corrugated "D" section is used for medium and low security palisade fencing.
------"Angle Steel " palisade fence as normal will use the 3.0-5.0mm thickness steel.

palisade fence-PF001



Steel Palisade Fencing Specification.
High Security Palisade Fencing Specification.

Height

Post Dimensions

Rail Dimensions

Support Legs

Corrugated Steel Palisades

1.2m

102x44 or 100x55

40x40x6mm

1

W - 2.0mm or D - 3.0mm

1.5m

102x44 or 100x55

40x40x6mm

1

W - 2.0mm or D - 3.0mm

1.8m

102x44 or 100x55

40x40x6mm

1

W - 2.0mm or D - 3.0mm

2.0m

102x44 or 100x55

45x45x6mm

1

W - 2.0mm or D - 3.0mm

2.1m

102x44 or 100x55

45x45x6mm

1

W - 2.0mm or D - 3.0mm

2.4m

102x44 or 100x55

45x45x6mm

1

W - 2.0mm or D - 3.0mm

2.7m

102x44 or 100x55

50x50x6mm

1

W - 2.0mm or D - 3.0mm

3.0m

127x76

50x50x6mm

2

W - 2.5mm or D - 3.5mm

3.6m

127x76

50x50x6mm

2

W - 2.5mm or D - 3.5mm



Metal Palisade Fence D and W Shape Palisade Security Fence System 1


Advantage of this hot dipped steel palisade fence:
1.Fence is using powder coating method,no rust,no flake off,no color fading,bright lastly and stable in color.
2.Easy assembly design makes installation more simple and quick.
3.Four layer anti corrosive treatment and more than twenty years service life fundamentally saves the cost.
4.Our security fencing is made of heavy duty steel that makes cutting the fence line near impossible. Your clients
can rest easy knowing that their garrison fencing will provide the protection needed for their properties.
5.To prevent corrosion our security fencing is fitted with steel caps. Unlike plastic caps, steel caps do not split over time.

Our steel palisade fence Features Include:
1.All pre - galvanised materials used.
2.All materials include high quality powder-coating.
3.14g Black powder coated tek screws or the option of upgrading to anti-vandal fixings.
4.4-hole rail brackets for additional strength for security fencing.
5.A complete range of accessories available. All powder coated to match the panels.

Metal Palisade Fence D and W Shape Palisade Security Fence System 2
High Security Palisade Fencing application.

Common uses include railway and track protection, schools, colleges and universities, research laboratories, motorways and highways protection, utility companies protection and around industrial sites.




Metal Palisade Fence D and W Shape Palisade Security Fence System 3
W Profile Galvanized Palisade Fencing-001
Metal Palisade Fence D and W Shape Palisade Security Fence System 4
W Profile Galvanized Palisade Fencing-002
Metal Palisade Fence D and W Shape Palisade Security Fence System 5
W Profile Galvanized Palisade Fencing-003

Metal Palisade Fence D and W Shape Palisade Security Fence System 6
