उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| आकार: | 2400 एच x 2300 एल | सतह का उपचार: | जस्ती |
|---|---|---|---|
| आईपीई पोस्ट आकार: | 100x55 मिमी | पीला: | डब्ल्यू अनुभाग |
| प्रकार: | फेंसिंग, ट्रेलिस एंड गेट्स, प्रोटेक्टिव ग्रिल प्रोफाइल या क्लैंपिंग प्रोफाइल | विशेषता: | आसानी से इकट्ठे, पर्यावरण के अनुकूल, निविड़ अंधकार, सड़ांध सबूत, कृंतक सबूत |
| धातु का प्रकार: | लोहा, स्टील, लोहा या जस्ती | फ़्रेम फ़िनिशिंग: | पीवीसी लेपित,पाउडर लेपित,एनोडाइज्ड |
| फ़्रेम सामग्री: | धातु | दबाव उपचारित लकड़ी का प्रकार: | गर्मी का इलाज, प्रकृति |
| रंग: | सफेद, काला, हरा, नीला, लाल | सतह का उपचार: | जस्ती+पीवीसी लेपित, इलेक्ट्रिक \ गर्म-डूबा हुआ जस्ती+पीवीसी \ पाउडर लेपित |
| आवेदन: | बाड़ जाल, इस्तेमाल किया, उद्यान, आवासीय | प्रयोग: | संरक्षण, उद्यान सजावट, भवन, उद्यान बाड़ / राजमार्ग / हवाई अड्डे |
| ईमेल: | devin@industrialmetalmesh.com | WHATSAPP: | +8615369013183 |
| प्रमुखता देना: | angle steel spear top fence,palisade fencing panel with spear top,wire mesh fence panels with steel |
||
Palisade Fence From Angle Steel Spear Top Palisade Fencing Panel
A steel picket fence is also known as a picket-welded fence, ornamental fence, or steel security fence. The panels are manufactured using the highest-strength steel pickets and rails, and are available in a wide range of sizes and styles. Panels are attached with high-strength steel brackets to galvanized and powder-coated square tubular steel posts. Steel Picket Fence is made of high-quality hot-dipped galvanized steel tube. The top vertical tube is pressed to spear by a heavy-duty punch.
The pales are made of hot formed and cold rolled steel belts.These belts offer both strength and rigidity combined with a long life span.
tower Palisade fence normally includes two types of pales, "W" profile, "D" profile .
|
Part Name
|
Specification
|
Component Quantity
|
|
|
H Post
|
100*55*5mm
|
1 pc
|
|
|
Rail Section
|
50*50*5mm
|
2 pcs
|
|
|
Pale Section
|
D Section
|
65*3.0mm
|
17 pcs
|
|
W Section
|
75*2.0mm
|
17 sets
|
|
|
Fish Plate
|
115*30*6mm or 140*39*8mm
|
2 pcs
|
|
|
Saddle Head M8 Botts
|
M8*40mm
|
34 sets
|
|
|
Cup Square M12 Botts
|
M12*30mm
|
4 sets
|
|
Specifications of security palisade fence:
PALISADE FENCE SPECIFICATIONS
• Post: 2400 High fence - 100×45 TFB
• Post: 3000 High Fence - 150 UB 14.0
• Rail: 50x50x6 EA
• Fish Plate: 40×8 140 long
• Corner Fish Plate: 40×8 215 long W Profile
• 'W' Pale: 71x21x3 W Profile
• Rail Fixings: M12x30 Cuphead Bolt and Shear Nut
• Pale Fixings: M8x25 T Bolt and Shear Nut or - Stainless Steel Huck Pin and Collar
• Mid Bay Support: M12x500 Threaded Rod and 2 x Nuts
palisade fence-PF001
| Panel Size | W-Section Pale: 70 mm | Horizontal Rail | Post | |||
| Height | Width | Pale thickness | Qty: Pale | Angle Steel | Square Post | I Post |
| 1.8 m | 2.75 m | 2/2.5/3 mm | 17 pcs | 40 × 40 × 4 mm, 50× 50 × 6 mm | 60 × 60 mm, 80 × 80 mm, 100 × 100 mm | 100 × 55 mm |
| 2.1 m | 2.75 m | 2/2.5/3 mm | 17 pcs | |||
| 2.4 m | 2.75 m | 2/2.5/3 mm | 17 pcs | |||
| 3.0 m | 2.75 m | 2/2.5/3/3.5 mm | 17 pcs | |||
| W-section Pale: 62 mm | ||||||
| 1.8 m | 2.75 m | 1.5/2/2.5 mm | 17 pcs | 40 × 40 × 4 mm, 50× 50 × 6 mm | 60 × 60 mm, 80 × 80 mm, 100 × 100 mm | 100 × 55 mm |
| 2.1 m | 2.75 m | 1.5/2/2.5 mm | 17 pcs | |||
| 2.4 m | 2.75 m | 1.5/2/2.5 mm | 17 pcs | |||
| 3.0 m | 2.75 m | 1.5/2/2.5 mm | 17 pcs | |||
| D-Section Pale: 65 mm | ||||||
| Panel Size | D-Section Pale: 65 mm | Horizontal Rail | Post | |||
| Height | Width | Pale thickness | Qty: Pale | Angle Steel | Square Post | I Post |
| 1.8 m | 2.75 m | 1.5/2/2.5/3 mm | 17 pcs | 40 × 40 × 4 mm, 50× 50 × 5 mm | 60 × 60 mm, 80 × 80 mm, 100 × 100 mm | 100 × 55 mm |
| 2.1 m | 2.75 m | 1.5/2/2.5/3 mm | 17 pcs | |||
| 2.4 m | 2.75 m | 1.5/2/2.5/3 mm | 17 pcs | |||
| 3.0 m | 2.75 m | 1.5/2/2.5/3 mm | 17 pcs | |||
